High Speed Impact Grinding Machine(Impact Pulverizer)-A Type

Share to:

HS-IMG Impact pulverizer is a high efficient, mechanical type ultra fine crusher, material crushing and classification in the same body and work independently, has compact structure, convenient operation, the fineness of powder can be automatic adjustment, simple and easy for maintenance.So it is widely used in non-metallic mineral, chemical, food, dye, organic materials, rubber, medicine and defense cutting-edge technology industries in the field of different super fine crushing.

  • HS-IMG-A
  • Hy-Sailing
Quantity:

A section chart


IMPACT APPLICATION FIELDApplication

Non-metallic mineral industry

Nano calcium, calcium ash, wollastonite, bentonite (concave) soil, brucite, aluminum hydroxide, kaolin, phosphate rock, talcum powder, tungsten, 108 glaze, mica, graphite, rare earth, phosphate, specularite...



Chemical industry

Petroleum coke, white carbon black, AC foaming agent, titanium dioxide, zinc stearate, polyvinyl alcohol, iron oxide red, melamine, activated carbon, carbon black, aluminum hydroxide, alumina, monoammonium phosphate, lead lead sulfate, boric acid, alkaline zinc carbonate, lithopone, compound fertilizers, industrial salt, silica gel, cobalt oxide, camphor powder...



 Food industry

Starch, sugar, AGAR, soybean meal, Chinese herbal medicine, cocoa, dried vegetables leaf...




Technical Parameter

Specification

CJM-420A

CJM-700A

CJM-1000A

CJM-1200A

Grinding dia(mm)

420

700

1000

1200

RPM

(r/min)

Rotary wheel

<5000

<3000

<2000

<1500

Classifier

<2900

<2900

<2900

<2900

Power

(kw)





Main motor

22

37~45

55~90

90~110

Classifier

3

7.5

22~30

30

Blower motor

7.5

15~18.5

45~75

75~90

Total

32.5

59.5~71

122~195

195~230

Size

(m)

Height

7.2

2.6

3.15

3.75

Area

13.5*4

13.5*4

11.2*3.5

13.5*4

Output(kg/h)

150~1000

300~2000

600~5000

1500~9000

Remark

Datas by the relative industry.


Advantages

Rouble-free, maintenance free: Can be seen from the picture, the hammer is on hammer plate through screws.Therefore, relative to the Raymond mill, crushing cavity without oil seal bearing, therefore, in addition to the normal wear need teardown replacement parts, do not need other maintenance.

Without over-smashing: you can see from the above series of figure, hammer plate is rotating, gear ring is static, that is to say: hammer and ring gear (also called guard) without direct contact.Result: the shattering of the material is through powder and collision of hammer head, powder and gear ring of the collision, collision between powders and powders to complete, so get crush powder, and "hard" because hardness will not be a one-off pieces.That is to say, the model was not produced pieces.Is not produced, powder and hard point the premise of fully separated.

Durable:Can be seen from the graph: hammer hit the surface with a layer of hard alloy welding on the piece, ring gear is to use high chromium casting material;Can be seen from the figure 4: hammer plate surface using a layer of wear-resistant welding layer of protection.Result: very wear-resistant parts.Add powder and hard point can fully separated without too much damage parts, so: the equipment is very durable, normal parts, can use more than one year.

Good Capability:Can be seen from the diagram, the crushing cavity diameter of 1 meter, because of the crushing cavity is bigger, so high grinding efficiency, high yield, the yield can be up to four tons.

Fine particle sizeCan be seen from the graph: classifier USES is wide blade vertical hierarchical structure, wide blade gap big guarantee not sticky powder;Vertical grading guarantee the size distribution of powder more concentrated than horizontal classifier.And because crushing ability, so fine powder containing high.In a word, Samhar CJM-A special impact mill in the domestic many factory in use process to prove: the models can help factory improve the quality of powder, reduce the production cost of unique advantages, has been many years industrial practice, the complete set of mature and reliable system.
