Application
Non-metallic mineral industry
Nano calcium, calcium ash, wollastonite, bentonite (concave) soil, brucite, aluminum hydroxide, kaolin, phosphate rock, talcum powder, tungsten, 108 glaze, mica, graphite, rare earth, phosphate, specularite...
Chemical industry
Petroleum coke, white carbon black, AC foaming agent, titanium dioxide, zinc stearate, polyvinyl alcohol, iron oxide red, melamine, activated carbon, carbon black, aluminum hydroxide, alumina, monoammonium phosphate, lead lead sulfate, boric acid, alkaline zinc carbonate, lithopone, compound fertilizers, industrial salt, silica gel, cobalt oxide, camphor powder...
Food industry
Starch, sugar, AGAR, soybean meal, Chinese herbal medicine, cocoa, dried vegetables leaf...
Specification | HS-IMG-1000N | HS-IMG-1500N |
Grinding dia(mm) | 1000 | 1500 |
RPM (r/min) | Rotary wheel | <1900 | <1600 |
Classifier | <960 | <960 |
Power (kw) | Main motor | 55 | 90 |
Classifier | 15 | 30 |
Blower motor | 55 | 75 |
Total | 125 | 195 |
Size (m) | Height | 3.15 | 3.95 |
Area | 11.2*3.5 | 12.5*4 |
Output(kg/h) | 2800~4500 | 4200~6000 |
Remark | Datas by the relative industry. |
Advantages：
① Rouble-free, maintenance free: Can be seen from the picture, the hammer is on hammer plate through screws.Therefore, relative to the Raymond mill, crushing cavity without oil seal bearing, therefore, in addition to the normal wear need teardown replacement parts, do not need other maintenance.
② Without over-smashing: you can see from the above series of figure, hammer plate is rotating, gear ring is static, that is to say: hammer and ring gear (also called guard) without direct contact.Result: the shattering of the material is through powder and collision of hammer head, powder and gear ring of the collision, collision between powders and powders to complete, so get crush powder, and "hard" because hardness will not be a one-off pieces.That is to say, the model was not produced pieces.Is not produced, powder and hard point the premise of fully separated.
③ Durable:Can be seen from the graph: hammer hit the surface with a layer of hard alloy welding on the piece, ring gear is to use high chromium casting material;Can be seen from the figure 4: hammer plate surface using a layer of wear-resistant welding layer of protection.Result: very wear-resistant parts.Add powder and hard point can fully separated without too much damage parts, so: the equipment is very durable, normal parts, can use more than one year.
④ Good Capability:Can be seen from the diagram, the crushing cavity diameter of 1 meter, because of the crushing cavity is bigger, so high grinding efficiency, high yield, the yield can be up to four tons.
⑤ Fine particle size：Can be seen from the graph: classifier USES is wide blade vertical hierarchical structure, wide blade gap big guarantee not sticky powder;Vertical grading guarantee the size distribution of powder more concentrated than horizontal classifier.And because crushing ability, so fine powder containing high.In a word, Samhar CJM-A special impact mill in the domestic many factory in use process to prove: the models can help factory improve the quality of powder, reduce the production cost of unique advantages, has been many years industrial practice, the complete set of mature and reliable system.
Application
Non-metallic mineral industry
Nano calcium, calcium ash, wollastonite, bentonite (concave) soil, brucite, aluminum hydroxide, kaolin, phosphate rock, talcum powder, tungsten, 108 glaze, mica, graphite, rare earth, phosphate, specularite...
Chemical industry
Petroleum coke, white carbon black, AC foaming agent, titanium dioxide, zinc stearate, polyvinyl alcohol, iron oxide red, melamine, activated carbon, carbon black, aluminum hydroxide, alumina, monoammonium phosphate, lead lead sulfate, boric acid, alkaline zinc carbonate, lithopone, compound fertilizers, industrial salt, silica gel, cobalt oxide, camphor powder...
Food industry
Starch, sugar, AGAR, soybean meal, Chinese herbal medicine, cocoa, dried vegetables leaf...
Specification | HS-IMG-1000N | HS-IMG-1500N |
Grinding dia(mm) | 1000 | 1500 |
RPM (r/min) | Rotary wheel | <1900 | <1600 |
Classifier | <960 | <960 |
Power (kw) | Main motor | 55 | 90 |
Classifier | 15 | 30 |
Blower motor | 55 | 75 |
Total | 125 | 195 |
Size (m) | Height | 3.15 | 3.95 |
Area | 11.2*3.5 | 12.5*4 |
Output(kg/h) | 2800~4500 | 4200~6000 |
Remark | Datas by the relative industry. |
Advantages：
① Rouble-free, maintenance free: Can be seen from the picture, the hammer is on hammer plate through screws.Therefore, relative to the Raymond mill, crushing cavity without oil seal bearing, therefore, in addition to the normal wear need teardown replacement parts, do not need other maintenance.
② Without over-smashing: you can see from the above series of figure, hammer plate is rotating, gear ring is static, that is to say: hammer and ring gear (also called guard) without direct contact.Result: the shattering of the material is through powder and collision of hammer head, powder and gear ring of the collision, collision between powders and powders to complete, so get crush powder, and "hard" because hardness will not be a one-off pieces.That is to say, the model was not produced pieces.Is not produced, powder and hard point the premise of fully separated.
③ Durable:Can be seen from the graph: hammer hit the surface with a layer of hard alloy welding on the piece, ring gear is to use high chromium casting material;Can be seen from the figure 4: hammer plate surface using a layer of wear-resistant welding layer of protection.Result: very wear-resistant parts.Add powder and hard point can fully separated without too much damage parts, so: the equipment is very durable, normal parts, can use more than one year.
④ Good Capability:Can be seen from the diagram, the crushing cavity diameter of 1 meter, because of the crushing cavity is bigger, so high grinding efficiency, high yield, the yield can be up to four tons.
⑤ Fine particle size：Can be seen from the graph: classifier USES is wide blade vertical hierarchical structure, wide blade gap big guarantee not sticky powder;Vertical grading guarantee the size distribution of powder more concentrated than horizontal classifier.And because crushing ability, so fine powder containing high.In a word, Samhar CJM-A special impact mill in the domestic many factory in use process to prove: the models can help factory improve the quality of powder, reduce the production cost of unique advantages, has been many years industrial practice, the complete set of mature and reliable system.
